6500-480 Heater/Fan Kit, 115V AC, 3.3 Amp

by DoorKing
Product Code: 6500-480
  • Allows gate operator systems to remain operating in cold environments.  Use if temperature routinely falls below 10°F (‐12°C).
  • Use this heater kit with the following models: 6500, 6524*, 6550.

* Heaters are active only when AC source power is present.

Shipping Eligible for shipping. Freight will apply.
Loading locations...

Please log in to see if you’re eligible to purchase this product.

$506.42
Shipping calculated at checkout.

6500-480 Heater/Fan Kit, 115V AC, 3.3 Amp is available for shipping.

No Tariff No import tariff
Working on offers?

Create estimates, easily organize bids by project name and order your selected products when the job is awarded. Export to pdf, share and update anytime.

Description

DoorKing 6500-480 Heater and Fan Kit provides thermostatically controlled heating inside compatible gate operator housings. Designed for cold climates where temperatures routinely drop below 10°F (-12°C), it combines a heater and fan to circulate warm air within the enclosure.

With the heater switch set to ON, the built-in thermostat automatically activates the heater and fan when the temperature inside the operator drops below 40°F (4°C). Both turn off when the internal temperature rises above 55°F (13°C). A manual OFF setting disables the heater and fan when heating is not needed.

This 115 VAC, 3.3-amp kit is designed for DoorKing 6500 operators and AC-powered 6524 operators configured for 115 VAC input power. The heater assembly mounts inside the operator using a mounting plate and bracket.

Compatibility: Do not install this kit on a 6500 operator equipped with the optional high voltage kit. For the 6524, use only with the AC-powered version operating on 115 VAC input power. Electrical supply wiring must be sized using the heater kit manual’s tables to account for the additional current draw.
