GHO1011 Gearhead Hoist Operator with Brake, 1HP, 115V, Single Phase

by Napoleon
Product Code: GHO1011
Shipping Eligible for shipping. Freight will apply.
Loading locations...
$2,017.78
Shipping calculated at checkout.

The GHO Series Industrial Duty Gear Head Operators deliver powerful, reliable performance for demanding commercial and industrial door applications. Engineered specifically for high lift and vertical lift sectional doors, rolling doors, and rolling grilles, these operators combine robust construction with versatile control options.

GHO1011 Gearhead Hoist Operator with Brake, 1HP, 115V, Single Phase is available for shipping.

No Tariff No import tariff

Please log in to see if you’re eligible to purchase this product.

Working on offers?

Create estimates, easily organize bids by project name and order your selected products when the job is awarded. Export to pdf, share and update anytime.

Description
  • 1/2 HP, 3/4 HP, 1 HP, 1 1/2 HP and 2 HP - 115V/230V-1 Phase Motor
  • 208/230/460/575V-3 Phase Motor
  • 3 Button station (NEMA 1)
  • 1650 RPM, high starting torque motor with overload protection
  • LX 100 BOARD Standard Features
  • B2 Mode, C2 Mode, D1 Mode, E2 Mode, T Mode, TS Mode
  • On board, Open, Close, & Stop for ease of setting limits
  • Photo-eyes included
  • Pre-wired to accept sensing devices
  • 24 Volt accessory power
  • On board (372 MHz) receiver capable of programming up to 20 transmitters
  • External receiver connection
  • NEMA 1 Electrical enclosure
  • Primary Drive: 44:1
  • 37.5 RPM output shaft speed
  • Door speed determined by the door system installed
  • Standard sprockets:
  • Sectional:  50B12 x 1” bore to 50B36 x 1” bore or 50B36 x 1 1/4” bore
  • Steel Rolling (Small to medium door):  50B12 x 1” bore to 50B36 x 1 1/4” bore
  • Steel Rolling (Large door):  50B12 x 1” bore to 50B48 x 1 1/4” bore or 50B48 x 1 1/2” bore
  • Warranty
  • 2 years on parts and motor
